6061 bare aluminum sheet can be processed into varieties of tempers, such as O, T4, T6, T651, etc. Among them, T4 and T6 are the most common ones for their good machanicability and weldability. Therefore, it is generally used industrial structure frame, which requires high anti-correction, such as truck, construction, ships, trolley bus, railway transit, etc.

ELEMRNTS	Magnesium	Silicon	Iron	Titanium	Copper	Manganese	Chromium	Zinc	Others Each	Others Total	B
CONTENT (WT%)	0.8-1.2	0.4-0.8	≤0.7	≤0.15	0.15-0.4	≤0.15	0.04-0.35	≤0.25	0.05	0.15	A





Alloy No. Temper	Tensile Strength	Yield Strength	Elongation	Thickness	Width	Length
	(MPa)	(MPa)	%	(mm)	(mm)	(mm)
T4	255	152	23	0.2-600	max2600	max16000
T6	345	290	13
T651	289	242	10

Features and Applications of 6061 Aluminum Plate/Sheet

Mg and Si are added to 6061 aluminum sheet, thus, it has middle strength and good resistance to correction. Cu and Zn can also improve the strength of aluminum alloy. Besides, 6061 aluminum sheet plate probably the most commonly available, heat treatable aluminum alloy. 6061 aluminum sheet can be easily cold worked and formed in the annealed condition. Stamping, bending, spinning, deep drawing are all readily accomplished using standard methods. By adding copper, 6061 aluminum sheet has 40% electrical conductivity.
